DESCRIPTION:
SAME DAY PRIORITY SHIPPING 1 TO 3 DAYS DELIVERY TIME
We highly recommend for our customer to please check the compatible vehicles list and match the photos with your original part if possible to make sure it fits your vehicle,
Thank You!
DSS AUTO PARTS
There is an additional shipping fee if you live in any of the US Protectorates such as Puerto Rico, US Virgin Islands, US Minor Outlying Islands, Guam, American Samoa and Northern Mariana Islands.
Specification:
4.5kW/24 Volt, CW, 11-Tooth Pinion
Interchanges:
Hyster: 3043803
Toyota: 28100-31625, 28100-31625-71, 28100-31625-74, 28100-47090, 28100-47090-C, 28100-47091
Denso: 028000-7240, 028000-7241, 028000-7242, 028000-7810, 028000-7811, 028000-7812
Lester: 16896
PIC: 190-817
Arrowhead: SND0070
Arrowhead Old: SND0144
BBB HD: 16896
BBB Ind: 16896
Carquest: 16896S
Carquest HD: 16896S
J & N Automotive: 410-52006, 410-52006R
Denso First Time Fit: 280-7003
MPA: 716896
NAPA HD: 716896
Wilson: 91-29-5219
Dixie Electric: NS-8404, S-8404
Andre Niermann: 017810
Application:
Make
Model
Year
Engine
Remarks
Toyota
3FD-33
80-88
All
w/AT 2H Engine Denso OSGR, 11T/24V, 4.5kW
Toyota
3FD-35
76-88
All
w/AT 2H Engine Denso OSGR, 11T/24V, 4.5kW
Toyota
3FD-40
76-88
All
w/AT 2H Engine Denso OSGR, 11T/24V, 4.5kW
Toyota
3FD-50
80-88
All
w/AT 2H Engine Denso OSGR, 11T/24V, 4.5kW
Toyota
3FD-60
80-88
All
w/AT 2H Engine Denso OSGR, 11T/24V, 4.5kW
Toyota
3FDE-35
76-88
All
2H Engine Denso OSGR, 11T/24V, 4.5kW
Toyota
FDC-33
76-88
All
2H Engine Denso OSGR, 11T/24V, 4.5kW
Toyota
FDC-35
76-88
All
2H Engine Denso OSGR, 11T/24V, 4.5kW
Toyota
FDC-45
76-88
All
2H Engine Denso OSGR, 11T/24V, 4.5kW
Toyota
Land Cruiser
85-87
L6 4.2L 4227cc
Denso OSGR, 11T/24V, 4.5kW
Toyota
Land Cruiser
81-86
L6 4.2L 4228cc 258cid
Denso OSGR, 11T/24V, 4.5kW
RETURN POLICY:
ALMOST ALL ITEMS HAVE 1 YEAR WARRANTY, PLEASE CHECK THE LISTING DESCRIPTION TO CLARIFY YOUR WARRANTY TIME.
AFTER 30 DAYS OF PURCHASE WE ARE NOT OBLIGATED TO PAY FOR THE RETURN SHIPPING FOR ANY RETURNS.
WE ARE WITHIN eBay SELLER GUIDELINES, AUTHORIZED TO CHARGE UP TO 50% OF THE TOTAL SALE TO ANY AND ALL MERCHANDISE THAT IS NOT RETURNED IN THE ORIGINAL CONDITION IT WAS SENT.
ITEMS CAN ONLY BE RETURNED/EXCHANGED TO US IN UNUSED CONDITION (IF FOUND DEFECTIVE OR WRONG PRODUCT SHIPPED)
IT IS THE BUYERS RESPONSIBILITY TO PACKAGE THE ITEM SAFE AND IN A BOX DURING THE RETURN PROCESS. FAILURE TO THIS WILL RESULT IN UP TO 50% ON THE RETURN AMOUNT.
ITEM THAT HAS BEEN INSTALLED WRONG OR ALTERED RESULT IN PARTIAL REFUND ONLY.
IF YOU RECEIVE THE ITEM THAT HAS QUALITY PROBLEMS OR DAMAGED, PLEASE PROVIDE US THE PHOTOS IMMEDIATELY AND CONTACT US.
IF AN ITEM GETS LOST IN TRANSIT, WE WILL BE ON CONTACT WITH THE SHIPPING CARRIER TO FIND THE ITEM AND TAKE CONTROL ASAP.
REFUND WILL BE ISSUED AFTER AN ITEM PASSES OUR INSPECTION AND APPROVED FOR A REFUND.
ALL PRESUMED DEFECTIVE OR WRONG ITEMS MUST OBTAIN AN AUTHORIZATION BEFORE RETURNING. ANY RETURNED PACKAGE WITHOUT AUTHORIZATION WILL BE REFUSED.
WE CANNOT REFUND ORIGINAL SHIPPING CHARGES IN CASE OF WRONG ITEM BOUGHT.
IF YOU REQUEST TO RETURN AN ITEM AND IT DOES NOT RETURN ON THE DATE IT IS SUPPOSED TO ARRIVE ON, WE WILL ONLY ISSUE A 80% REFUND TO THE BUYER
ONCE THE ITEM HAS BEEN RETURNED, A REFUND WILL BE MADE TO THE BUYER MINUS ORIGINAL SHIPPING FEE TO THE BUYER AND THE RESTOCKING FEE, BUYERS ARE ALSO RESPONSIBLE FOR RETURN SHIPPING CHARGES IF PASSES 30 DAY AFTER DATE OF PURCHASE.
LOCAL PICK UP AVAILABLE: We recommend for all our customers to search DSS Auto Parts on google to find our location.
SAME DAY PRIORITY SHIPPING 1 TO 3 DAYS DELIVERY TIME
We highly recommend for our customer to please check the compatible vehicles list and match the photos with your original part if possible to make sure it fits your vehicle,
Thank You!
DSS AUTO PARTS
There is an additional shipping fee if you live in any of the US Protectorates such as Puerto Rico, US Virgin Islands, US Minor Outlying Islands, Guam, American Samoa and Northern Mariana Islands.
Specification:
4.5kW/24 Volt, CW, 11-Tooth Pinion
Interchanges:
| Hyster: 3043803 |
| Toyota: 28100-31625, 28100-31625-71, 28100-31625-74, 28100-47090, 28100-47090-C, 28100-47091 |
| Denso: 028000-7240, 028000-7241, 028000-7242, 028000-7810, 028000-7811, 028000-7812 |
| Lester: 16896 |
| PIC: 190-817 |
| Arrowhead: SND0070 |
| Arrowhead Old: SND0144 |
| BBB HD: 16896 |
| BBB Ind: 16896 |
| Carquest: 16896S |
| Carquest HD: 16896S |
| J & N Automotive: 410-52006, 410-52006R |
| Denso First Time Fit: 280-7003 |
| MPA: 716896 |
| NAPA HD: 716896 |
| Wilson: 91-29-5219 |
| Dixie Electric: NS-8404, S-8404 |
| Andre Niermann: 017810 |
Application:
| Make | Model | Year | Engine | Remarks |
|---|---|---|---|---|
| Toyota | 3FD-33 | 80-88 | All | w/AT 2H Engine Denso OSGR, 11T/24V, 4.5kW |
| Toyota | 3FD-35 | 76-88 | All | w/AT 2H Engine Denso OSGR, 11T/24V, 4.5kW |
| Toyota | 3FD-40 | 76-88 | All | w/AT 2H Engine Denso OSGR, 11T/24V, 4.5kW |
| Toyota | 3FD-50 | 80-88 | All | w/AT 2H Engine Denso OSGR, 11T/24V, 4.5kW |
| Toyota | 3FD-60 | 80-88 | All | w/AT 2H Engine Denso OSGR, 11T/24V, 4.5kW |
| Toyota | 3FDE-35 | 76-88 | All | 2H Engine Denso OSGR, 11T/24V, 4.5kW |
| Toyota | FDC-33 | 76-88 | All | 2H Engine Denso OSGR, 11T/24V, 4.5kW |
| Toyota | FDC-35 | 76-88 | All | 2H Engine Denso OSGR, 11T/24V, 4.5kW |
| Toyota | FDC-45 | 76-88 | All | 2H Engine Denso OSGR, 11T/24V, 4.5kW |
| Toyota | Land Cruiser | 85-87 | L6 4.2L 4227cc | Denso OSGR, 11T/24V, 4.5kW |
| Toyota | Land Cruiser | 81-86 | L6 4.2L 4228cc 258cid | Denso OSGR, 11T/24V, 4.5kW |
